Key Features
Modular Design – Fully configurable with quaternary or binary pumps, autosamplers, column compartments, and detectors to fit your specific workflow.
High Precision & Reproducibility – Delivers consistent retention times and peak areas, ideal for routine analysis and complex research.
Advanced Autosampler – Supports large sample capacity, automated dilution, and precise injection for high-throughput laboratories.
Temperature-Controlled Column Compartment – Ensures reproducible separations by maintaining consistent column temperatures.
Flexible Detection Options – Compatible with UV/Vis, diode array (DAD), fluorescence, and refractive index detectors for versatile applications.
User-Friendly Software Integration – Controlled via Agilent OpenLab CDS or ChemStation for seamless method development, instrument control, and data analysis.
Wide Range of Applications – Suitable for pharmaceuticals, biopharmaceuticals, food and beverage testing, environmental analysis, and chemical research.
Low Maintenance & Reliability – Designed for extended operational life with reduced downtime and minimal routine maintenance.
High Sensitivity & Resolution – Optimized fluidics and detectors provide superior peak resolution and signal-to-noise performance.
Scalable Workflow – Easily upgraded with additional modules to meet growing laboratory demands.
Technical Specifications
Pump (Quaternary / Binary)
Flow Rate Range: 0.001 – 5 mL/min (adjustable in 0.001 mL/min increments)
Recommended Operational Range: 0.05 – 5 mL/min
Flow Precision: ≤ 0.07 % RSD or ≤ 0.02 min SD
Flow Accuracy: ± 1 % or 10 µL/min
Maximum Operating Pressure: Up to 60 MPa (600 bar / 8702 psi)
Pressure Pulsation: < 2 % amplitude (typically <1.3 %)
Solvent Composition Precision: < 0.15 % RSD
Solvent Composition Accuracy: ± 0.35 % absolute
Autosampler
Injection Volume: 0.1 – 90 µL (in 0.1 µL steps)
Injection Precision: < 0.15 % RSD or SD < 10 nL
Maximum Pressure: Up to 800 bar
Sample Viscosity Range: 0.2 – 5 cP
Sample Capacity: Configurable (multiple drawer options available)
Fast Injection Cycle: < 10 s with multi-directional washes and seat backflush to minimize carryover (< 0.003 %)
Column Compartment (Multicolumn Thermostat)
Temperature Range: 4 °C to 110 °C (down to ~20 °C below ambient)
Temperature Stability: ± 0.03 °C
Temperature Accuracy: ± 0.5 °C
Temperature Precision: 0.05 °C
Turnaround Time:
-
-
Ambient → 40 °C: ~5 min
-
40 °C → 20 °C: ~10 min
-
25 °C → 100 °C: < 30 min
Detector Options
Detection Type: 1024‑element photodiode array
Wavelength Range: 190 – 950 nm
Data Rate: Up to 120 Hz
Short-Term Noise: < ± 0.7 × 10⁻⁵ AU (ASTM, at 254 nm & 750 nm)
Drift (254 nm): < 0.9 × 10⁻³ AU/h
Linear Absorbance Range: > 2 AU at 265 nm
Wavelength Accuracy: ± 1 nm
General & System Features
Maximum Operating Pressure: Up to 600 bar (UHPLC-ready in some configurations)
Modular Design: Configurable with pumps, detectors, thermostats, and samplers
Software Control: Agilent OpenLab CDS or compatible platforms for method setup, control, and data processing
Carryover Minimization: Multi-wash and backflush capabilities for reduced sample contamination
