MDPro M4 3D Scan Bladder Scanner
The MDPro M4 3D Scan Bladder Scanner is a state-of-the-art, non-invasive medical device designed for rapid and accurate assessment of bladder volume and urinary retention. Utilizing advanced 3D imaging technology, this scanner provides precise, real-time volumetric measurements to support diagnosis, catheterization decisions, and post-operative care in clinical settings.
Compact and portable, the MDPro M4 is suitable for use in hospitals, nursing homes, urology clinics, and bedside patient care. Its intuitive interface, automated measurement algorithms, and ergonomic design ensure efficiency, patient comfort, and reliability for healthcare professionals.
Key Features
Advanced 3D Imaging Technology
Provides accurate, volumetric bladder assessment with real-time imaging for reliable clinical decisions.
Non-Invasive & Comfortable
Eliminates the need for catheterization while delivering precise measurements, enhancing patient safety and comfort.
Rapid & Automated Measurements
Fast scanning and automated algorithms reduce exam time and workflow interruptions.
Portable & Lightweight Design
Easy to transport between wards or rooms, suitable for bedside and outpatient use.
User-Friendly Touchscreen Interface
Intuitive controls and clear graphical display simplify operation for clinicians of all experience levels.
Data Storage & Connectivity
Internal memory for patient records with options to export data via USB or network integration.
Clinical Applications
Bladder volume assessment and urinary retention evaluation
Pre- and post-catheterization monitoring
Post-operative care and recovery
Urology and nephrology examinations
Bedside monitoring in hospitals and nursing facilities
Advantages for Healthcare Professionals
Improves diagnostic accuracy and patient safety
Reduces unnecessary catheterizations
Enhances workflow efficiency with rapid, automated scanning
Portable design supports use across multiple clinical settings
Reliable and reproducible measurements for consistent patient care
The MDPro M4 3D Scan Bladder Scanner combines advanced 3D ultrasound technology, ease of use, and portability to deliver a powerful solution for accurate bladder assessment and improved clinical workflow.
Specifications – MDPro M4 3D Scan Bladder Scanner
Measurement & Performance
Measurement Type: 3D volumetric bladder scanning
Bladder Volume Range: 0–999 mL
Measurement Accuracy: ±5% or ±15 mL (whichever is greater)
Scan Time: ≤10 seconds per measurement
Automatic Volume Calculation: Yes, with real-time 3D display
Display & User Interface
Display: 7-inch high-resolution color touchscreen
User Interface: Intuitive menu with guided scanning and automated results
Data Storage: Internal memory for up to 500 patient records
Connectivity: USB, optional network/DICOM integration
Operational Features
Patient Type: Adult, pediatric, and geriatric settings
Probe Type: 3D ultrasound curved array probe
Battery Operated: Rechargeable lithium-ion battery
Portability: Lightweight handheld design (~1.2 kg)
Physical & Power
Dimensions: Approx. 220 × 160 × 50 mm
Weight: ~1.2–1.5 kg
Power Supply: 100–240 V AC adapter / rechargeable battery
Operating Temperature: 10–40°C
Storage Temperature: –20–60°C
